Powerful Outdoor Visibility
Even in Direct Sunlight

The Outdoor QLED Display is built for digital signage environments where visibility, brightness and durability cannot be compromised. With brightness of up to 4000 nits, it is designed to keep advertising, public information and promotional content clearly visible even under direct sunlight. QLED technology with a 105% colour gamut helps deliver vivid and detailed visuals, while the 178° viewing angle provides a broad viewing experience from different positions.
Available in sizes from 32 to 86 inches, the display can be selected according to the scale and requirements of the installation. Trace Enterprise provides high-performance outdoor digital signage solutions in Pakistan for businesses and organisations that need reliable visual communication in demanding outdoor environments.

Built to Handle Challenging Outdoor Conditions

Outdoor digital signage needs more than a bright screen. It needs protection against changing weather and demanding environmental conditions. This display features an IP67-rated enclosure, designed to provide protection against water, dust and harsh weather. Its IK10-rated tempered glass also offers strong resistance against impact, vandalism and external debris. The wide operating temperature design allows the display to function in temperatures ranging from approximately -30°C to 55°C, making it suitable for challenging environments. This combination of weather and impact protection makes it a strong choice for outdoor advertising, public information, transportation and commercial installations. Trace Enterprise supplies durable outdoor display technology in Pakistan for projects where reliability matters.

Clearer Images With Advanced Glare Control

Outdoor screens can lose visual impact when sunlight and reflections interfere with the image. The Outdoor QLED Display addresses this challenge with anti-reflective glass and optical bonding technology designed to reduce reflections and improve image clarity. The bonded construction helps eliminate the air gap between the LCD panel and tempered glass, supporting improved brightness and contrast. The display also offers a wide 178° viewing angle, allowing content to remain visible from a broad range of positions. Its QLED technology and 105% colour gamut further support rich and vibrant visuals. For brands displaying advertisements, promotions or public information outdoors, Trace Enterprise delivers professional digital signage solutions in Pakistan designed for strong visual performance.

Smart Brightness for Efficient Outdoor Operation

Keeping an outdoor display bright enough during the day while avoiding unnecessary power consumption at other times can be challenging. The display incorporates a built-in auto-brightness sensor that adjusts screen brightness according to surrounding light conditions. This helps maintain visibility while supporting more efficient operation and reduced power consumption. The display is also designed for continuous outdoor use, with a fanless and filterless construction that helps reduce maintenance requirements. Available configurations support both portrait and landscape orientations, providing greater flexibility for different signage layouts. Trace Enterprise offers outdoor QLED display solutions in Pakistan for applications including smart cities, bus stations, drive-throughs, shopping malls, outdoor menu boards and business environments.

Product Features

Up to 4000-Nit Brightness

QLED Colour Performance

IP67 Weather Protection

IK10 Impact Resistance

Intelligent Brightness Control

Wide Temperature Operation

Product Specifications

Display Information

Panel Size
32 inch | 43 inch | 55 inch | 65 inch | 75 inch | 86 inch
Resolution
32 inch: 1920 × 1080
43 inch: 1920 × 1080
55 inch: 1920 × 1080
65 inch: 3840 × 2160
75 inch: 3840 × 2160
86 inch: 3840 × 2160
Brightness
4000 Nits
Active Area (mm)
32 inch: 698.4 × 392.85
43 inch: 941.184 × 529.416
55 inch: 1209.6 × 680.4
65 inch: 1428.48 × 803.52
75 inch: 1649.66 × 927.936
86 inch: 1895.04 × 1066.5
Viewing Angle
178/178
Aspect Ratio
16:9
Display Colors
1.07B, 105%
LED Life Time
50,000 hours
Blackening Defect Free
Up to 110?
Orientation
Portrait & Landscape
Brightness Control
Sensor Built-in

Mechanical

Bezel Width (T/B/L/R)
32 inch: 26.7/26.7/27.8/27.8 mm
43 inch: 26.7/26.7/27.8/27.8 mm
55 inch: 29.5/29.5/28.5/28.5 mm
65 inch: 29.5/29.5/28.5/28.5 mm
75 inch: 29.5/29.5/28.5/28.5 mm
86 inch: 29.5/29.5/28.5/28.5 mm
Overall Dimensions
32 inch: 750 × 450 × 126 mm
43 inch: 1001 × 586 × 125.5 mm
55 inch: 1268 × 737 × 125.5 mm
65 inch: 1487 × 861 × 140.5 mm
75 inch: 1708 × 982 × 130 mm
86 inch: 1952 × 1124 × 135 mm
Net Weight (Display Only)
32 inch: 25 KG
43 inch: 36 KG
55 inch: 60 KG
65 inch: 90 KG
75 inch: 120 KG
86 inch: 150 KG

Connectivity

Operating System
Android 7.1 / Windows 10
CPU
RK3288 / i5 / i7
ROM
2G / 4G / 8G
RAM
16G / 32G / 256G SSD
Network
WIFI/RJ45
Ports
USB ×2, HDMI OUT ×1, RJ45 ×1, POWER PORT ×1

Special Features

Tempered Glass
Anti-Reflective Glass with IK10 Impact-resistant
Process
Optical Bonded
Weatherproof Design
IP67
Cooling System
Fanless + Filterless
Operating Temperature
−30°C ~ 55°C

Power

Power Supply
AC 110~240V
Rated Frequency
50/60Hz
